    Specifications
    Product Code 9E1000I<>
    Specifications
    Product Code 9E1000I
    Description EATON 9E1000I 1000VA/800W Tower Online double conversion USB UPS
    General
    Topology Online double conversion
    Configuration Tower
    Part Number 9E1000I
    Rating (VA/Watts) 1000/800
    Dimensions (H x W x D, mm) 356 x 228 x 144
    Weight (kg) 9.5
    Electrical Input
    Connection (1) IEC-320-C14
    Input Voltage Range 176-300V without derating (up to 100-300V with derating)
    Nominal Voltage 208/220/230/240V
    Frequency 50/60 Hz autoselection
    Frequency Range 40-70 Hz
    Electrical Output
    Voltages 208V*/220V/230V/240V ±1%
    Voltage THD <2% for 100% linear load
    Outlets (4) IEC-320-C13
    Overload Capacity 105%-130% : 60s, 130%-150% : 10s, >150% : ≥ 300ms
    Efficiency (Normal Mode) Up to 91% in Online mode
    Output Frequency 50/60 Hz autoselect
    Communications
    Communication Ports 1 USB port + 1 RS232 serial port (USB and RS232 ports cannot be used simultaneously)
    Communication Slot 1 slot for Network-M2, ModBus-MS or Relay-MS cards
    Power Management Software Intelligent Power Editions
    Environmental & Standards
    Audible Noise <37 dB @ typical load
    Operating Temperature 0 to 40°C
    Safety markings IEC/EN 62040-1
    EMC Markings IEC/EN 62040 -2
    Approvals CE, CB report (TUV)
